R114.075.134 Specifications
Manufacturer: Radiall
Part Number: R114.075.134
NSN: 5935-01-628-2661
Connector Type: RF Coaxial Connector
Interface: SMA Plug
Impedance: 50 Ohm
Configuration: Straight
Termination Type: Crimp
Cable Attachment: Coaxial Cable
Body Material: Stainless Steel
Contact Plating: Gold
Frequency Range: DC to 18 GHz
Coupling Mechanism: Threaded
Compliance: MIL-STD Compatible
Packaging: Factory
Key Features
The R114.075.134 is a high-performance SMA plug connector engineered for reliable RF signal transmission. It supports 50 ohm impedance for consistent high-frequency performance. Additionally, the straight configuration simplifies coaxial cable routing in compact assemblies. The crimp termination ensures secure mechanical and electrical connection. Because it incorporates gold-plated contacts, it maintains low contact resistance and stable signal integrity. As a result, it delivers dependable RF performance in aerospace, defense, and industrial applications.
Applications
Military aircraft RF communication systems
Ground vehicle antenna assemblies
Naval radar and signal modules
Aerospace instrumentation interfaces
Defense electronic warfare systems
High-frequency test equipment
Secure tactical communication networks
Precision RF cable assemblies
Product Overview
The R114.075.134 from Radiall delivers dependable RF connectivity for demanding environments. First, its 50 ohm impedance supports stable signal transmission across high-frequency systems. Furthermore, the threaded SMA coupling mechanism ensures secure mating under vibration. Because it is constructed with stainless steel, it provides mechanical durability and corrosion resistance.
Moreover, the crimp termination method allows repeatable cable assembly performance. In addition, the gold-plated center contact supports consistent conductivity over time. Therefore, it is suitable for both new RF harness builds and maintenance replacements. Overall, this SMA plug connector provides reliable signal integrity, mechanical strength, and professional-grade RF performance.
