RLR07C5600FSB14 Specifications
Manufacturer: Vishay
Part Number: RLR07C5600FSB14
NSN: 5905-00-721-1755
Product Type: Fixed Resistor
Resistance Value: 560 Ω
Tolerance: ±1%
Power Rating: 0.25 W
Resistor Type: Metal Film
Temperature Coefficient: ±100 ppm/°C
Mounting Type: Through Hole
Lead Style: Axial Lead
Military Specification: MIL-R-39017
Operating Temperature Range: -55°C to +175°C
Packaging: Factory
Key Features
The RLR07C5600FSB14 is a precision metal film resistor designed for high-reliability electronic systems. It provides a resistance value of 560 ohms with ±1% tolerance for accurate circuit performance. Additionally, the metal film construction ensures excellent stability across wide temperature ranges. The axial lead configuration allows easy integration into through-hole printed circuit boards and legacy electronic assemblies. Because the resistor meets MIL-R-39017 requirements, it is widely used in aerospace, defense, and industrial control systems. As a result, it delivers dependable electrical performance in demanding operating environments.
Applications
Military communication electronics
Aerospace avionics circuits
Industrial instrumentation systems
Analog signal conditioning networks
Voltage divider circuits
Power regulation circuits
Embedded control platforms
High-reliability electronic assemblies
Product Overview
The RLR07C5600FSB14 from Vishay provides stable resistance control for demanding electronic applications. First, the 560 ohm resistance value supports current limiting, voltage divider networks, and signal conditioning circuits. Furthermore, the ±1% tolerance ensures predictable electrical behavior in precision analog designs. Because metal film technology offers improved stability compared to carbon resistors, it maintains accurate resistance values over long operational lifetimes.
Moreover, compliance with MIL-R-39017 standards enables integration into military-qualified electronic systems. In addition, the axial lead format simplifies installation in traditional through-hole PCB assemblies. Therefore, the resistor is well suited for maintenance replacement programs and new system designs. Overall, this Vishay resistor delivers reliable electrical performance, stable resistance characteristics, and long service life in mission-critical electronics.
