Specifications
Manufacturer: State of the Art, Inc.
Part Number: S0402CPX000
Date Code: 1637
Quantity Available: 50 pieces
Sell Format: Sold as one lot
Product Type: Thick Film Chip Jumper
Case Size: 0402
Resistance: 0 Ω jumper
Tolerance: Not applicable for jumper
Power Rating: 1/16W / 50 mW
Temperature Coefficient: Not applicable for jumper
Construction: Thick film on alumina
Termination Type: Wraparound termination
Termination Finish: Sn60 over nickel, solderable
Mounting Style: Surface Mount
Grade: Standard Production
Key Features
0402 surface-mount thick film chip jumper
0 Ω jumper configuration
Designed for circuit routing and board-level configuration
1/16W / 50 mW power rating
Thick film on alumina construction
Wraparound termination for SMT assembly
Sn60 over nickel solderable termination finish
Compact package for dense PCB layouts
Useful for jumper links and circuit options
Sold as one lot of 50 pieces
Applications
Industrial control boards
PCB jumper links
Circuit routing configurations
Engineering change implementation
Test and measurement equipment
Communication hardware
Repair and replacement inventory
Prototype PCB builds
Low-power electronic assemblies
Engineering stock and maintenance inventory
Product Description
The S0402CPX000 from State of the Art, Inc. is a 0402 thick film chip jumper designed for compact surface-mount circuit assemblies. This component provides a 0 Ω jumper configuration, making it useful for PCB trace routing, circuit option selection, and board-level configuration points. In addition, the 0402 case size helps conserve board space in dense electronic designs.
This part uses thick film on alumina construction with wraparound terminations. As a result, it is suitable for standard SMT placement and soldering processes. The Sn60 over nickel termination finish supports solderable assembly requirements, while the 1/16W / 50 mW rating makes the device appropriate for low-power jumper and routing positions. Since this is a 0 Ω jumper, standard resistance tolerance and temperature coefficient values are not applied in the same way as fixed-value resistors.
The part number indicates standard production grade. Therefore, this item should not be listed as high-reliability or full MIL-spec qualified unless additional traceability, screening, or manufacturer documentation is available. However, State of the Art, Inc. is known for resistive products used in industrial, aerospace, defense, communication, and high-reliability applications.
Cyndtek® is offering this item as one complete lot of 50 pieces. Because these chip jumpers are low-cost components, they are sold by lot rather than individually. This makes the listing practical for buyers needing replacement stock, engineering inventory, prototype support, or small production quantities. The listed date code is 1637, and the supplied quantity is 50 pieces.
To request pricing or availability for S0402CPX000, visit our Cyndtek shop or contact sales@cyndtek.com with your quantity, target price, and required delivery schedule
For additional available stock, browse our full inventory.
