SEAF-40-01-S-08-2-RA-GP Specifications
Manufacturer: Samtec
Part Number: SEAF-40-01-S-08-2-RA-GP
Connector Series: SEAF high-speed array
Connector Type: Board-to-board mezzanine connector
Number of Positions: 40 positions
Pitch Spacing: 0.80 mm
Mounting Style: Surface mount
Orientation: Right angle mating
Contact Type: Female contacts
Termination Method: Solder reflow
Contact Plating: Gold over nickel
Housing Material: High-temperature thermoplastic
Operating Temperature Range: -55 °C to +125 °C
Impedance Control: Controlled impedance design
Packaging Type: Tape and reel
Key Features
This high-speed mezzanine connector supports dense board stacking with controlled impedance performance. It maintains signal integrity at higher data rates. Additionally, the right-angle configuration allows efficient PCB layout options. The gold-plated contacts improve reliability over repeated mating cycles. As a result, long-term electrical performance remains stable. Moreover, the high-temperature housing supports lead-free reflow assembly. Therefore, it fits well into automated production environments.
Applications
High-speed computing modules
FPGA and processor mezzanine cards
Networking and switching equipment
Data acquisition systems
Industrial embedded controllers
Telecommunications line cards
Storage and server backplanes
Test and measurement platforms
Advanced imaging systems
Product Overview
The SEAF-40-01-S-08-2-RA-GP from Samtec is designed for high-performance board-to-board interconnections. First, its 0.80 mm pitch supports compact designs with increased signal density. Additionally, the controlled impedance structure helps preserve signal quality in high-speed applications. As data rates continue to rise, this connector supports reliable transmission across stacked PCBs. Furthermore, the right-angle mating style improves mechanical flexibility during layout. Consequently, designers can optimize routing without compromising performance. While compact, the connector delivers strong mechanical retention. Therefore, it remains dependable in vibration-prone environments. Overall, this mezzanine connector balances density, signal integrity, and manufacturability for advanced electronic systems.
Contact Us
For pricing, availability, or technical support regarding the SEAF-40-01-S-08-2-RA-GP connector, our team is ready to assist. Cyndtek supplies factory-new electronic components for commercial and industrial use. Contact our sales team to align quantities with your build schedule. Email Sales@Cyndtek.com for prompt assistance.
