Samtec SHF‑111‑01‑L‑D‑SM Specifications
Manufacturer: Samtec
Product Category: Connector
Connector Type: Shrouded PCB Header (Wire-to-Board / Board-to-Board)
Number of Positions: 22
Pitch: 0.050″ (1.27 mm)
Rows: 2
Contact Type: Male pins
Contact Plating: Gold in mating area, tin plated posts
Insulation Material: Liquid crystal polymer (LCP)
Mounting Style: Surface Mount Technology (SMT)
Termination Style: Solder
Operating Temperature Range: –55 °C to +125 °C
Current Rating: ~3 A per contact
Material Flammability Rating: UL94 V-0
Category: Connector
Key Features:
Moreover, the SHF-111-01-L-D-SM is a shrouded header that supports high-density PCB interconnects with a 1.27 mm pitch. Additionally, its dual-row configuration enhances signal routing options on the board. Also, gold-plated mating areas improve conductivity and corrosion resistance. Furthermore, robust phosphor bronze contacts sustain reliable electrical performance. Finally, liquid crystal polymer housing provides mechanical strength and thermal stability.
Applications:
High-density board-to-board interconnects
Embedded system headers
Telecommunications modules
Networking equipment interfaces
Industrial automation boards
Product Overview:
The SHF-111-01-L-D-SM from Samtec is a compact, shrouded PCB header designed to deliver reliable electrical connections in dense layouts. Consequently, the 22-position, 1.27 mm pitch array supports modern high-signal-count interconnects. Moreover, its dual rows and push-pull style ease mating with matching cable or board assemblies. Also, robust plating and quality materials ensure consistent performance across multiple mating cycles. In addition, the broad temperature range allows use in industrial and commercial environments. Therefore, designers can use this connector in data-rich embedded systems, telecom interfaces, and automation boards where space and signal integrity matter. Moreover, the surface mount termination streamlines manufacturing for automated assembly.
