SI2302CDS-T1-GE3 Specifications
Manufacturer: Vishay Siliconix
Part Type: N-Channel MOSFET
Drain-to-Source Voltage (VDS): 20 V
Continuous Drain Current (ID): 2.3 A
RDS(ON): 85 mΩ at VGS = 2.5 V
Gate Threshold Voltage (VGS(th)): 0.8 V to 1.5 V
Total Gate Charge (Qg): 2.4 nC (typical)
Package Type: SOT-23
Mounting Type: Surface Mount
Operating Temperature Range: -55°C to +150°C
Power Dissipation: 1.25 W
Input Capacitance (Ciss): 340 pF
Drive Voltage: 1.8 V to 4.5 V logic level
Fast Switching Speed: Yes
RoHS Compliant: Yes
ESD Protection: Built-in
Key Features
The SI2302CDS-T1-GE3 is a compact N-channel MOSFET optimized for low-voltage switching in space-limited designs. With a maximum drain-to-source voltage of 20 V and an RDS(ON) as low as 85 mΩ at 2.5 V gate drive, it delivers efficient power switching for portable and embedded systems. It also supports fast switching speeds and low gate charge, which minimizes switching losses. Built-in ESD protection and a rugged SOT-23 package make it ideal for applications that demand reliability and compactness.
Applications
DC-DC converters
Battery-powered electronics
Load switches in portable devices
LED drivers
Sensor power control
Wireless communication modules
Tablet and smartphone subsystems
Small motor control
Embedded system power rails
Consumer wearables
Product Overview
The SI2302CDS-T1-GE3 offers a reliable solution for switching applications in compact and low-power electronics. Its ability to handle up to 2.3 A of continuous current with low RDS(ON) ensures efficient performance in power-sensitive environments. With support for logic-level gate drive, the device integrates easily into modern microcontroller-based systems. The fast switching behavior reduces power dissipation during transitions, helping to extend battery life in portable designs. Designed for thermal efficiency and space savings, it excels in applications where board real estate and power efficiency are both priorities.
