SI5341A-D-GM Specifications
Manufacturer: Skyworks Solutions, Inc.
Part Number: SI5341A-D-GM
Product Type: Ultra-Low Jitter Clock Generator
Number of Outputs: 10
Input Frequency Range: 10 MHz to 750 MHz (differential), 10 MHz to 250 MHz (LVCMOS), 25 MHz to 54 MHz (crystal)
Output Frequency Range: 100 Hz to 1.028 GHz
Output Signal Formats: LVDS, LVPECL, LVCMOS, CML, HCSL
RMS Phase Jitter: 90 fs (typical)
Core Supply Voltage (VDD): 1.8V ±5%
Analog Supply Voltage (VDDA): 3.3V ±5%
Output Supply Voltage (VDDO): 1.8V, 2.5V, or 3.3V
Package / Case: 64-QFN (9mm x 9mm)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant
Key Features
The SI5341A-D-GM is an ultra-flexible clock generator built to support complex timing needs. It features ten outputs with multiple format options including LVDS, LVPECL, LVCMOS, CML, and HCSL. Additionally, it supports a broad input range, accepting differential, LVCMOS, or crystal sources. Its RMS phase jitter is just 90 fs, making it ideal for low-noise applications. Output frequencies are programmable from 100 Hz up to 1.028 GHz. Furthermore, it operates with a 1.8V core and 3.3V analog supply, while supporting various output voltages. Its design allows seamless integration into modern digital platforms.
Applications
High-performance networking equipment
Telecommunications systems
Data center infrastructure
Test and measurement instruments
Broadcast video systems
Industrial automation
Any-frequency clock translation
Clocking for FPGAs, processors, and memory
Product Overview
The SI5341A-D-GM offers a powerful solution for generating multiple synchronized clock signals. It replaces several discrete components, simplifying the design. Because of its ultra-low jitter, it maintains excellent signal integrity. Designers can program each output for both frequency and format. As a result, the part suits a wide range of system requirements. Its input flexibility further improves design versatility. The compact 64-QFN package makes board layout easier, even in space-constrained systems. Additionally, it operates across a wide temperature range, ensuring reliable performance in demanding environments.
