SII1160CTU Specifications
Manufacturer: Silicon Image
Part Number: SII1160CTU
Product Type: PanelLink Digital Transmitter IC
Supply Voltage: 3.3 V
Interface Type: PanelLink / DVI Digital Video Interface
Package Type: TQFP-100
Mounting Type: Surface Mount
Input Interface: Parallel Digital Video
Output Interface: TMDS Digital Transmission
Supported Resolution: High Resolution Digital Video Support
Operating Temperature Range: -40°C to +85°C
Applications Class: Digital Display Interface
RoHS Status: RoHS Compliant
Packaging: Factory
Key Features
The SII1160CTU is a PanelLink digital transmitter designed to convert parallel digital video data into high-speed TMDS signals. It operates from a 3.3 volt supply and supports digital video transmission to flat panel displays and DVI compatible devices. Additionally, the integrated TMDS transmitter circuitry allows efficient conversion of video data streams into high-speed differential signals. Because the device supports high resolution display interfaces, engineers frequently use it in digital display systems and video processing hardware.
Applications
Flat panel display interfaces
Digital video transmission systems
Industrial display controllers
Medical imaging display equipment
Embedded graphics controllers
Digital signage systems
Computer display interface hardware
Video processing electronics
Product Overview
The SII1160CTU from Silicon Image provides a reliable digital video transmission interface for flat panel display systems. First, the device converts parallel video input data into TMDS encoded differential signals used in PanelLink and DVI display interfaces. This conversion allows digital video systems to transmit high resolution display data over differential signaling channels.
Additionally, the IC operates from a single 3.3 volt supply which simplifies integration into modern digital video electronics. Because display systems often require high bandwidth signal transmission, the TMDS interface supports reliable high-speed digital communication between video sources and display panels.
Moreover, the TQFP-100 surface mount package allows integration into compact digital display controller boards. Engineers frequently use this device in embedded graphics systems, industrial display equipment, and digital video transmission hardware.
Therefore, the SII1160CTU remains a practical solution for digital video interface applications that require reliable PanelLink or DVI transmission capabilities.
