SN74LVC125ADR

SN74LVC125ADR

$0.07

IC BUF NON-INVERT 3.6V 14SOIC
  • Manufacturer: Texas Instruments
  • Part Number: SN74LVC125ADR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: 15+

Availability: 2537 in stock

SKU TSX051B Category Brand:

SN74LVC125ADR Specifications

Manufacturer: Texas Instruments
Part Number: SN74LVC125ADR
Product Type: Quadruple Bus Buffer Gate with 3-State Outputs
Supply Voltage Range: 1.65 V to 3.6 V
Input Voltage Range: 0 V to 5.5 V
Output Voltage Range: 0 V to VCC
High-Level Output Current (IOH): -24 mA at 3 V VCC
Low-Level Output Current (IOL): 24 mA at 3 V VCC
Maximum Propagation Delay (tpd): 4.8 ns at 3.3 V
Package / Case: 14-SOIC
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +125°C
RoHS Status: RoHS Compliant

Key Features

The SN74LVC125ADR is a quadruple bus buffer gate designed for operation within a supply voltage range of 1.65 V to 3.6 V. Each of its four independent buffers features 3-state outputs, controlled by individual output-enable (OE) inputs. This configuration allows for efficient management of multiple data lines. The device supports input voltages up to 5.5 V, making it suitable for mixed-voltage environments. With a maximum propagation delay of 4.8 ns at 3.3 V, it ensures swift signal transmission. Additionally, the SN74LVC125ADR is characterized by its high output drive capability, delivering up to 24 mA, which is beneficial for driving moderate loads. The device also exhibits robust performance across a wide operating temperature range from -40°C to +125°C, ensuring reliability in various environmental conditions.

Applications

Bus interface applications
Memory systems
Peripheral interfaces
Industrial control systems
Communication equipment

Product Overview

The SN74LVC125ADR from Texas Instruments is engineered to provide reliable and efficient buffering for bus interface applications. Its four independent buffers, each with 3-state outputs, offer flexibility in managing multiple data lines. The device’s ability to accept input voltages up to 5.5 V allows for seamless integration into mixed-voltage systems. With a maximum propagation delay of 4.8 ns at 3.3 V, it facilitates rapid data transfer, enhancing overall system performance. The high output drive capability of ±24 mA ensures that it can effectively drive moderate loads without compromising signal integrity. Packaged in a 14-SOIC case and designed for surface-mount installation, the SN74LVC125ADR supports efficient assembly processes. Its wide operating temperature range from -40°C to +125°C ensures consistent performance across diverse environmental conditions, making it a versatile choice for various applications requiring dependable bus buffering.
