SN74LVC1G08DSFR

SN74LVC1G08DSFR

$0.10

IC GATE AND 1CH 2-INP 6SON JR
  • Manufacturer: Texas Instruments
  • Part Number: SN74LVC1G08DSFR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: 1808

Availability: 31 in stock

SKU PAC004B-10 Category Brand:

SN74LVC1G08DSFR Specifications

Manufacturer: Texas Instruments
Part Type: Single 2-Input AND Gate
Logic Family: LVC
Number of Inputs: 2
Number of Outputs: 1
Voltage Supply Range: 1.65 V to 5.5 V
Output Type: Push-Pull
Propagation Delay: 3.8 ns at 3.3 V
Operating Temperature Range: -40°C to +125°C
Package Type: SON-6 (2 mm × 2 mm)
Mounting Type: Surface Mount
Input Type: CMOS, TTL Compatible
Drive Strength: ±32 mA at 4.5 V
Power Consumption: Low
RoHS Compliant: Yes
ESD Protection: 2 kV HBM

Key Features

The SN74LVC1G08DSFR is a high-performance, single 2-input AND gate designed for low-power and high-speed applications. With broad voltage compatibility and support for both TTL and CMOS logic levels, it easily fits into a wide range of designs. Its fast switching and low propagation delay make it ideal for timing-critical applications. The push-pull output allows strong drive capability, while the SON-6 package offers a space-saving solution for compact PCBs. Additionally, integrated ESD protection ensures reliability in rugged environments.

Applications

Logic expansion in embedded systems
Timing control circuits
Power sequencing logic
Smart home devices
Industrial I/O modules
Automotive subsystems
Sensor interface logic
Communication equipment
Mobile electronics
Wearable computing devices

Product Overview

The SN74LVC1G08DSFR is tailored for use in both low-power and high-speed logic environments. Its compact footprint and low power draw make it ideal for portable electronics and space-constrained embedded boards. It accepts a wide supply range from 1.65 V to 5.5 V and offers robust drive strength, ensuring clean logic transitions. Its compatibility with both TTL and CMOS inputs allows for seamless integration into mixed-signal designs. With a temperature rating up to 125°C and built-in ESD protection, it performs reliably across industrial and consumer applications alike.
