SN75176BDR

SN75176BDR

$0.40

IC TRANSCEIVER HALF 1/1 8SOP
  • Manufacturer: Texas Instruments
  • Part Number: SN75176BDR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: 1813

Availability: 1769 in stock

SKU TSX050B Category Brand:

SN75176BDR Specifications

Manufacturer: Texas Instruments
Part Number: SN75176BDR
Product Type: Differential Bus Transceiver
Number of Drivers/Receivers: 1 Driver / 1 Receiver
Duplex: Half
Data Rate: Up to 10 Mbps
Supply Voltage Range: 4.75 V to 5.25 V
Driver Output Voltage Range: -7 V to +12 V
Receiver Input Voltage Range: -7 V to +12 V
Receiver Input Sensitivity: ±200 mV
Hysteresis: 50 mV (typical)
Driver Output Current: ±60 mA
Package / Case: 8-SOIC
Mounting Type: Surface Mount
Operating Temperature Range: 0°C to +70°C
RoHS Status: RoHS Compliant

Key Features

The SN75176BDR is a reliable differential bus transceiver engineered for multipoint communication lines. It combines one driver and one receiver in a compact 8-pin package. Moreover, it operates in half-duplex mode and supports data rates up to 10 Mbps. The device is compatible with TIA/EIA-422-B and TIA/EIA-485-A standards, which makes it ideal for RS-485 and RS-422 systems. In addition, it handles wide voltage swings from -7 V to +12 V on both the driver and receiver. It also includes thermal shutdown and current limiting to protect against line faults.

Applications

RS-485 and RS-422 systems
Industrial automation
Motor control systems
Building automation
Telecommunications

Product Overview

The SN75176BDR from Texas Instruments delivers efficient and dependable communication for systems requiring differential signaling. It features a robust design that handles up to ±60 mA output current. Its wide input and output voltage ranges improve noise immunity, especially in electrically harsh environments. Because of its small 8-SOIC footprint and surface-mount design, it fits easily into compact PCBs. Additionally, the device uses only a 5 V supply and offers a typical receiver hysteresis of 50 mV, which helps reduce false triggering. With these features, it offers a balanced mix of performance, protection, and versatility.
