STPS30L30DJF-TR

STPS30L30DJF-TR

$0.50

DIODE SCHOTTKY 30V 30A POWERFLAT JR
  • Manufacturer: STMicroelectronics
  • Part Number: STPS30L30DJF-TR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: N/A

Availability: 32 in stock

SKU JR016 Category Brand:

STPS30L30DJF-TR Specifications

Manufacturer: STMicroelectronics
Part Type: Schottky Rectifier
Configuration: Dual Common Cathode
Maximum Repetitive Reverse Voltage (VRRM): 30 V
Average Forward Current (IF(AV)): 2 × 15 A
Forward Voltage Drop (VF): 0.48 V at 15 A
Reverse Current (IR): 1 mA at 30 V
Operating Temperature Range: -40°C to +150°C
Package Type: D2PAK (TO-263AB)
Mounting Type: Surface Mount
Reverse Recovery Time: Negligible (Schottky behavior)
Power Dissipation: High Efficiency
Polarity: Cathode Center Tap
Thermal Resistance (Junction to Case): 1.5°C/W
RoHS Compliant: Yes
High Surge Capability: Yes

Key Features

The STPS30L30DJF-TR is a dual low-voltage Schottky rectifier that offers fast switching, low forward voltage drop, and high current capability. With a 30 V maximum reverse voltage and a total average forward current of 30 A, it efficiently handles power conversion in high-performance circuits. The D2PAK surface-mount package allows for excellent thermal management, while the common cathode configuration supports symmetrical high-current pathways. Furthermore, its negligible reverse recovery time ensures reduced power loss and improved system efficiency.

Applications

High-efficiency power supply designs
DC-DC converters in telecom systems
Solar panel bypass protection
Battery charging modules
Load switching circuits
Secondary side rectification in SMPS
Automotive ECU power rails
High-performance LED drivers
Voltage regulation loops
Power distribution networks

Product Overview

Engineered for energy-efficient rectification, the STPS30L30DJF-TR excels in low-voltage, high-current power applications. Its Schottky architecture allows for very low conduction losses and fast switching with minimal heat buildup. The common cathode structure makes it ideal for dual-path power designs and polarity-protected outputs. Additionally, its D2PAK package supports strong thermal conductivity, enabling reliable operation even under high load conditions. Whether in automotive, telecom, or industrial power systems, this rectifier offers stable and efficient performance.
