T495X476M035ATE200
Manufacturer: KEMET
Part Type: Tantalum Capacitor, Solid, MnO₂
Capacitance: 47 µF
Rated Voltage: 35 V DC
Tolerance: ±20%
ESR (Equivalent Series Resistance): 200 mΩ
Case Size / Code: X (EIA 2917, 7.3 mm × 4.3 mm)
Mounting Type: Surface Mount (SMD)
Series: T495 (Surge Robust)
Operating Temperature Range: -55°C to +125°C
Dissipation Factor: 6% max at 120 Hz
Leakage Current: 0.01 CV (typical)
Polarity: Polarized
RoHS Compliant: Yes
Applications: Power filtering, decoupling, and energy storage in high-reliability systems
Key Features
The T495X476M035ATE200 is a robust surface-mount tantalum capacitor from KEMET’s surge-robust T495 series. Offering 47 µF capacitance with a 35 V rating, it is engineered for demanding environments. Its enhanced surge current capability ensures stable performance in power supply decoupling and filtering applications. With low ESR of 200 mΩ and a high reliability MnO₂ construction, it provides excellent stability across wide temperature ranges. Its compact EIA 2917 case size enables space-saving designs in advanced electronics.
Applications
DC-DC converters
Telecommunication equipment
Automotive electronic control units
Industrial automation controllers
Medical electronics power supplies
Consumer electronic devices
Defense and aerospace electronics
LED driver circuits
Test and measurement equipment
Server and networking systems
Product Overview
The KEMET T495X476M035ATE200 combines surge-robust design with stable capacitance for reliable energy storage and filtering. Operating up to 125°C, it provides long-term performance in harsh automotive and industrial environments. Its low ESR enables improved efficiency in high-frequency applications, while the polarized structure ensures dependable integration into regulated power circuits. With compact dimensions and high capacitance density, this capacitor is ideal for advanced systems requiring consistent voltage smoothing and noise suppression.
