TCM1-83X+ Specifications
Manufacturer: Bourns
Part Number: TCM1-83X+
Component Type: Ferrite Bead / EMI Suppressor
Impedance: 80 Ω at 100 MHz
Rated Current: 600 mA
DC Resistance (DCR): Low resistance for efficient performance
Package / Case: 0603 (1608 metric)
Mounting Type: Surface mount
Operating Temperature Range: -55 °C to +125 °C
RoHS Compliance: Yes
Key Features
The TCM1-83X+ ferrite bead provides effective EMI suppression in compact surface mount applications. Additionally, its 80 Ω impedance helps reduce high-frequency noise. Moreover, the low DC resistance maintains efficient current flow. Furthermore, the small 0603 package supports automated PCB assembly and high-density board layouts.
Applications
EMI/RFI noise filtering on power lines
Signal line noise suppression
Embedded system power filtering
Telecommunications circuitry
Industrial control noise reduction
Consumer electronics power integrity
Portable device EMI management
High-speed digital line conditioning
Product Overview
The Bourns TCM1-83X+ ferrite bead is designed for effective suppression of electromagnetic interference in surface mount circuits. Specifically, it offers 80 Ω impedance at 100 MHz, helping reduce unwanted high-frequency noise in power and signal paths. As a result, system stability and signal integrity improve in sensitive designs. Moreover, the low DC resistance characteristic keeps energy loss minimal, which benefits overall circuit efficiency. Therefore, this component supports clean power delivery and noise-free signal lines.
In addition, the compact 0603 surface mount package enables efficient board usage and supports automated manufacturing. Furthermore, the wide operating temperature range ensures dependable performance in varied environmental conditions. Consequently, the TCM1-83X+ fits well into both consumer and industrial electronic applications requiring robust EMI mitigation. Because of its balanced design and ease of integration, this ferrite bead remains a practical choice for modern electronic systems.
