TLV1543CDW

TLV1543CDW Specifications

Manufacturer: Texas Instruments
Part Number: TLV1543CDW
Product Type: 10-Bit Analog-to-Digital Converter (ADC)
Input Voltage Range: 0 V to VCC
Reference Voltage Range: 2.5 V to VCC
Analog Input Channels: 11
Self-Test Modes: 3 built-in
Total Unadjusted Error: ±1 LSB Max
Supply Voltage: 3 V to 5.5 V
Package / Case: 20-Lead SOIC (300 mil)
Mounting Type: Surface Mount
Operating Temperature Range: 0°C to +70°C
RoHS Status: RoHS Compliant

Key Features

The TLV1543CDW is a 10-bit successive-approximation analog-to-digital converter (ADC) from Texas Instruments. It integrates an 11-channel multiplexer, allowing selection among multiple analog inputs or internal self-test voltages. The device operates over a supply voltage range of 3 V to 5.5 V, making it suitable for various applications. Its automatic sample-and-hold function ensures accurate conversions, and the total unadjusted error is limited to ±1 least significant bit (LSB). The ADC includes an on-chip system clock and provides an end-of-conversion (EOC) output signal, facilitating synchronization with microcontrollers or digital signal processors.

Applications

Data acquisition systems
Sensor interfacing
Portable instrumentation
Battery-powered devices
Industrial process control

Product Overview

The TLV1543CDW ADC offers a high level of integration and performance for analog-to-digital conversion tasks. Its 11-channel input multiplexer enables connection to multiple analog sources, while the built-in self-test modes enhance reliability by allowing internal diagnostics. Operating within a supply voltage range of 3 V to 5.5 V, it is compatible with both 3.3 V and 5 V systems. The device’s inherent sample-and-hold function captures input signals accurately. The ±1 LSB total unadjusted error ensures precision in digital representation. The inclusion of an on-chip system clock and EOC output simplifies interfacing with digital systems, making it a versatile choice for various applications.
