TNPW0805442RBEEA Specifications
Manufacturer: Vishay
Part Number: TNPW0805442RBEEA
Product Type: Precision Thin Film Chip Resistor
Resistance: 442 Ohm
Resistance Tolerance: ±0.1%
Power Rating: 0.25 W
Package Size: 0805 SMD
Mounting Type: Surface Mount
Resistor Technology: Thin Film
Temperature Coefficient: ±25 ppm/°C
Operating Temperature Range: -55°C to +155°C
Termination Style: Wraparound SMD Termination
Series: TNPW Precision Thin Film
Applications Class: Precision Electronics
Packaging: Factory
Key Features
The TNPW0805442RBEEA is a precision thin film chip resistor designed for high accuracy electronic circuits. It provides a resistance value of 442 ohm with a tight ±0.1% tolerance. Additionally, the thin film construction supports excellent stability and low electrical noise performance. Because the resistor uses precision trimming technology, it maintains consistent resistance values across temperature changes. As a result, engineers frequently use this resistor in instrumentation and precision analog circuits.
Applications
Precision analog measurement circuits
Instrumentation amplifier networks
Sensor signal conditioning circuits
Industrial control electronics
Medical monitoring equipment
High accuracy voltage divider networks
Data acquisition systems
Calibration and reference circuits
Product Overview
The TNPW0805442RBEEA resistor from Vishay supports precision electronic designs that require accurate resistance values and stable electrical performance. First, the thin film resistor construction provides tight tolerance and excellent long-term stability.
Additionally, the 0805 surface mount package allows compact circuit layouts used in modern electronic assemblies. Because many measurement circuits rely on stable resistor networks, designers frequently select thin film resistors for improved accuracy and predictable electrical characteristics.
Moreover, the ±0.1% tolerance and low temperature coefficient help maintain stable resistance across temperature variations. This stability supports reliable operation in instrumentation, industrial electronics, and precision control systems.
Therefore, engineers commonly use the TNPW0805442RBEEA in analog signal paths and calibration networks where resistor accuracy directly affects system performance.
