TPD2EUSB30DRTR

TPD2EUSB30DRTR

$0.15

TVS DIODE 5.5VWM 8VC SOT3
  • Manufacturer: Texas Instruments
  • Part Number: TPD2EUSB30DRTR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: N/A

Availability: 78 in stock

SKU PAC004C-1 Category Brand:

TPD2EUSB30DRTR Specifications

Manufacturer: Texas Instruments
Part Number: TPD2EUSB30DRTR
Product Type: Dual-Channel ESD Protection Diode
Number of Channels: 2
Reverse Stand-Off Voltage: 5.5 V
Breakdown Voltage: 7 V (minimum)
Clamping Voltage: 8 V at 1 A current
Peak Pulse Current: 5 A (8/20 µs waveform)
Capacitance: 0.7 pF (typical)
Dynamic Resistance: 0.6 Ω (typical)
ESD Protection Level: ±8 kV (IEC 61000-4-2 contact discharge)
Surge Protection Level: 5 A (IEC 61000-4-5)
Package / Case: SOT (3-pin)
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The TPD2EUSB30DRTR from Texas Instruments is a dual-channel Electrostatic Discharge (ESD) protection diode designed to safeguard high-speed data interfaces such as USB 3.0. It supports data rates up to 5 Gbps, ensuring signal integrity while providing robust protection. The device offers a low capacitance of 0.7 pF, minimizing signal distortion in high-frequency applications. With a reverse stand-off voltage of 5.5 V and a breakdown voltage of at least 7 V, it effectively clamps transient voltages, protecting sensitive circuitry. The TPD2EUSB30DRTR is capable of withstanding ESD strikes up to ±8 kV as per IEC 61000-4-2 standards and can handle surge currents up to 5 A in accordance with IEC 61000-4-5 specifications. Its dynamic resistance of 0.6 Ω ensures efficient clamping during transient events. The device is housed in a compact SOT-3 package, making it suitable for space-constrained designs.

Applications

Protecting USB 3.0 ports in laptops and desktops to ensure reliable data transfer.
Safeguarding HDMI interfaces in set-top boxes against electrostatic discharges.
Shielding eSATA ports in external storage devices from voltage transients.
Ensuring the longevity of high-speed data lines in media players by preventing ESD damage.
Providing surge protection for Thunderbolt interfaces in high-performance computing equipment.

Product Overview

Texas Instruments’ TPD2EUSB30DRTR is engineered to deliver robust ESD and surge protection for high-speed data interfaces. Its low capacitance and dynamic resistance ensure minimal signal degradation. This making it ideal for applications requiring data rates up to 5 Gbps. The device’s compliance with IEC standards for ESD and surge protection guarantees reliable performance in environments prone to electrostatic discharges and voltage transients. The compact SOT-3 package facilitates easy integration into various electronic designs, particularly those with limited board space. By incorporating the TPD2EUSB30DRTR, designers can enhance the durability and reliability of sensitive data interfaces in consumer electronics and computing devices.
