TS3A5018RSVR

TS3A5018RSVR

$0.25

IC SWITCH SPDT X 4 10OHM 16UQFN JR
  • Manufacturer: Texas Instruments
  • Part Number: TS3A5018RSVR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: N/A

Availability: 173 in stock

SKU PAC004B-12 Category Brand:

TS3A5018RSVR Specifications

Manufacturer: Texas Instruments
Part Type: Analog Switch (Dual SPDT)
Switch Configuration: Dual Single-Pole Double-Throw (SPDT)
Channels: 2
On-State Resistance (RON): 4 Ω (typical)
Operating Voltage Range: 1.8 V to 5.5 V
Bandwidth: 300 MHz (typical at 5 V)
ON-State Leakage Current: 1 µA (max)
Break-Before-Make Switching: Yes
Control Interface: CMOS/TTL Compatible
Package Type: VQFN-16 (RSV)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
Switching Time: 20 ns (typical)
Power Supply Type: Single
RoHS Compliant: Yes

Key Features

The TS3A5018RSVR is a high-bandwidth, low on-resistance analog switch ideal for signal routing in precision analog and digital systems. It features two independently controlled SPDT switches that support break-before-make operation to prevent signal overlap. With a low typical RON of 4 ohms and wide voltage compatibility from 1.8 V to 5.5 V, this device minimizes signal distortion and power loss. The compact VQFN-16 package allows dense layout while maintaining high-frequency performance up to 300 MHz.

Applications

Signal multiplexing in audio systems
Portable medical instrumentation
Test and measurement equipment
Digital multimedia routing
Mobile communication hardware
Analog front-end signal switching
Low-power embedded systems
Peripheral interface selection
Consumer electronic switching
Data acquisition systems

Product Overview

Designed for precision and flexibility, the TS3A5018RSVR delivers excellent signal fidelity with minimal distortion. Its dual-SPDT configuration is well-suited for systems that require compact, high-speed switching. The device ensures signal integrity with low RON and minimal leakage, even when switching rapidly between analog or digital sources. Additionally, break-before-make logic prevents shorting during transitions. Its wide voltage range makes it a strong fit for both battery-operated and line-powered designs. From consumer electronics to industrial control, it offers dependable switching performance.
