TST-106-01-S-D Specifications
Manufacturer: Samtec
Part Number: TST-106-01-S-D
Product Type: Header, Breakaway
Connector Type: Dual Row, Straight
Number of Positions: 12 (2 x 6)
Contact Finish: Gold
Contact Finish Thickness: 10 µin (0.25 µm)
Mounting Type: Through Hole
Row Spacing: 0.100″ (2.54mm)
Pitch: 0.100″ (2.54mm)
Termination Style: Solder
Insulation Height: 0.235″ (5.97mm)
Operating Temperature Range: -55°C to +125°C
Packaging: Bulk
RoHS Status: RoHS Compliant
Key Features
The TST-106-01-S-D is a high-reliability through-hole header from Samtec, designed for versatile PCB applications. Featuring a 2×6 dual-row configuration and a standard 0.100″ (2.54mm) pitch, this breakaway-style header supports straightforward integration with a wide variety of mating connectors. Its gold-plated contacts ensure long-term signal integrity, while the rugged through-hole design offers mechanical stability during both assembly and operation. The component’s compact profile makes it well-suited for space-constrained layouts without sacrificing performance or durability.
Applications
General-purpose PCB interconnects
Prototyping and development boards
Consumer electronics
Industrial control systems
Test equipment and instrumentation
Embedded systems
Product Overview
The TST-106-01-S-D by Samtec delivers a robust and flexible interconnect solution for standard 0.100″ pitch board layouts. As part of the TST series, this dual-row, through-hole header offers 12 total positions (2×6 configuration) and features gold-plated contacts for excellent conductivity and corrosion resistance. Its 10 µin gold plating enhances long-term performance in demanding electrical environments. Furthermore, the solder tail design allows for solid mechanical attachment to the PCB, contributing to system durability. Thanks to its compact insulation height and standard spacing, it integrates seamlessly into a variety of system designs. Whether you’re developing a prototype or building out a production run it is a reliable choice that balances form, function, and ease of assembly.
