TSW-105-07-F-D Specifications
Manufacturer: Samtec
Part Number: TSW-105-07-F-D
Connector Type: Terminal strip header
Contact Style: Pin header
Number of Positions: 10 positions
Number of Rows: 2 rows
Pitch: 2.54 mm
Row Spacing: 2.54 mm
Orientation: Straight
Termination Style: Through-hole
Mounting Type: PCB mount
Contact Material: Phosphor bronze
Contact Plating: Gold flash over nickel
Insulation Material: High temperature plastic
Operating Temperature Range: -55 °C to +125 °C
Key Features
The TSW-105-07-F-D provides reliable board-to-board connectivity in standard pitch designs. Additionally, the dual-row configuration supports increased signal density. Moreover, gold flash plating improves contact reliability and mating consistency. Furthermore, the high temperature housing supports common soldering processes.
Applications
Board-to-board interconnects
Embedded computing modules
Industrial control PCBs
Development and prototyping boards
Power management assemblies
Test and measurement equipment
Automation control systems
General-purpose PCB headers
Product Overview
The Samtec TSW-105-07-F-D terminal strip header is designed for dependable through-hole PCB interconnections. Specifically, it offers a dual-row layout with standard 2.54 mm spacing, which supports broad compatibility with mating connectors. As a result, designers can integrate this header into both new and existing layouts with minimal adjustment. Moreover, the straight orientation simplifies vertical board stacking and alignment. Therefore, assembly and mating are more consistent.
In addition, the phosphor bronze contacts provide strong mechanical durability and stable electrical performance. Furthermore, the gold flash plating enhances corrosion resistance and supports repeated mating cycles. Consequently, long-term connection reliability is improved. The high temperature plastic housing also withstands elevated soldering temperatures. As a result, the connector integrates well into automated manufacturing environments.
Because of its standard footprint and robust construction, the TSW-105-07-F-D fits a wide range of industrial and embedded applications. Moreover, the dual-row design allows higher pin counts without increasing connector length. Therefore, board space is used more efficiently. The extended operating temperature range further supports use in demanding environments. Consequently, dependable performance is maintained over time.
Overall, this terminal strip header balances compatibility, durability, and ease of integration. Therefore, it remains a practical choice for designers requiring reliable dual-row PCB header solutions.
