X1G003831002300

X1G003831002300 Specifications

Manufacturer: Seiko Epson Corporation
Part Number: X1G003831002300
Product Type: Simple Packaged Crystal Oscillator (SPXO)
Frequency: 25.000 MHz
Frequency Stability: ±50 ppm
Supply Voltage: 3.3 V
Current Consumption: 6 mA (maximum)
Output Type: CMOS
Operating Temperature Range: -40°C to +85°C
Storage Temperature Range: -55°C to +125°C
Start-Up Time: 10 ms (maximum)
Output Load: 15 pF
Duty Cycle: 45% to 55%
Rise/Fall Time: 5 ns (maximum)
Package Type: SG7050CAN (7.0 mm × 5.0 mm)
RoHS Status: RoHS Compliant

Key Features

The X1G003831002300 from Seiko Epson Corporation is a high-performance Simple Packaged Crystal Oscillator (SPXO). Designed to deliver precise 25.000 MHz frequency output with ±50 ppm stability. Operating at a supply voltage of 3.3 V, it ensures low power consumption with a maximum current draw of 6 mA. The CMOS output facilitates seamless integration into digital circuits. Meanwhile the robust SG7050CAN package measures 7.0 mm × 5.0 mm, providing durability and ease of mounting. With an operating temperature range spanning from -40°C to +85°C, this oscillator maintains reliable performance across diverse environmental conditions.

Applications

Networking equipment requiring stable clock signals
Industrial automation systems demanding precise timing
Telecommunications devices necessitating reliable frequency sources
Consumer electronics with stringent timing requirements
Medical instrumentation relying on accurate oscillation

Product Overview

Seiko Epson’s X1G003831002300 crystal oscillator exemplifies precision engineering, offering a stable 25.000 MHz output with tight frequency stability of ±50 ppm. Its low power consumption and CMOS output make it an ideal choice for energy-efficient applications. The SG7050CAN package not only ensures a compact footprint but also provides robustness suitable for various industrial and commercial environments. Designed to operate reliably over a wide temperature range, this oscillator is versatile for use in networking, telecommunications, and consumer electronics. Compliance with RoHS standards underscores Seiko Epson’s commitment to environmentally responsible manufacturing.
