XGL3520-201MEC Specifications
Manufacturer: TDK
Part Number: XGL3520-201MEC
Component Type: Multilayer Ceramic Chip Inductor (MLCI)
Inductance: 200 µH
Tolerance: ±20 %
Rated Current: Moderate current handling
DC Resistance (DCR): Low resistance for efficient operation
Shielding: Shielded ferrite core
Package / Case: 3520 (1409 metric)
Mounting Type: Surface mount
Operating Temperature Range: -40 °C to +125 °C
RoHS Compliance: Yes
Key Features
The XGL3520-201MEC delivers reliable inductance in a space-efficient, shielded surface mount package. Additionally, its ferrite core minimizes electromagnetic interference and improves magnetic coupling. Moreover, the low DC resistance supports energy-efficient current flow. Furthermore, the 3520 footprint allows higher inductance in compact power systems.
Applications
DC/DC converter power stages
Power supply noise suppression
Embedded system power management
Telecommunications power circuits
Industrial automation control boards
Portable and battery-powered systems
Voltage regulation modules
High-efficiency power designs
Product Overview
The TDK XGL3520-201MEC multilayer ceramic chip inductor provides dependable inductance with efficient current handling for a range of power conversion and noise suppression applications. Specifically, it offers a 200 µH inductance value with low DC resistance, which helps maintain high efficiency in DC/DC systems and filtering networks. As a result, designers can optimize power stages and reduce energy losses. Moreover, the shielded ferrite core limits stray emissions and enhances magnetic coupling, which benefits noise-sensitive designs.
In addition, the compact 3520 surface mount package supports automated assembly and maximizes board real estate usage. Furthermore, stable performance across a wide temperature range ensures reliable operation in both consumer and industrial environments. Consequently, this inductor suits power system designers focused on compact and robust solutions. Because of its balance of inductance value, current capacity, and space-saving design, the XGL3520-201MEC remains a practical choice for modern electronic power applications.
