S03KZZ2P-A Specifications:

Manufacturer: Alpha Novatech Inc.
Product Series: zQSFP Plus – zQSFP1
Part Number: S03KZZ2P-A
Material: Thermoplastic
Color: Black
Number of Contacts: 38
Contact Material: Copper Alloy
Contact Plating: Gold over Nickel (0.762 µm thickness)
Current Rating: 0.5 A
Voltage Rating: 30 V AC/DC
Mating Cycles: 50
Mounting Style: Surface Mount
Orientation: Right Angle
Termination Method: Surface Mount
Keying: No
PCB Retention: Yes
Ground to Panel/PCB: Yes
UL Certification: E29179
Product Type: Receptacle
Packaging: Bulk

Key Features:

High-Speed Data Transmission: Designed for 25 Gbps data rates, suitable for high-bandwidth applications.
Compact Design: Features a 30 mm x 30 mm footprint with a height of 25 mm, optimizing space in electronic assemblies.
Efficient Thermal Management: Incorporates hexagonal pin fins that enhance natural convection, providing a thermal resistance of 9.5 °C/W, effectively dissipating heat from high-power components.
Durable Construction: Made from black anodized aluminum (A6063), ensuring robustness and longevity.
Flexible Mounting: Surface mount termination allows for easy integration into various PCB designs.
Compliance: Meets RoHS 3 standards, ensuring environmental safety.

Applications:

High-Speed Networking: Ideal for applications requiring rapid data transmission, such as network switches and routers.
Data Centers: Enhances performance in data centers by efficiently managing heat dissipation in high-density configurations.
Telecommunications: Supports reliable data communication in telecom equipment.
Enterprise Servers: Improves server performance by maintaining optimal operating temperatures for critical components.
Storage Systems: Ensures efficient heat management in high-performance storage solutions.

Product Overview:

The S03KZZ2P-A is a high-performance heat sink manufactured by Alpha Novatech Inc., specifically designed for 25 Gbps data transmission applications. Its compact 30 mm x 30 mm footprint with a height of 25 mm makes it suitable for space-constrained environments. The heat sink’s hexagonal pin fins are strategically arranged to enhance natural convection, achieving a thermal resistance of 9.5 °C/W, effectively dissipating heat from high-power components. Constructed from durable black anodized aluminum (A6063), it ensures longevity and robustness. The surface mount termination facilitates easy integration into various PCB designs, and its compliance with RoHS 3 standards underscores its commitment to environmental safety.
