050/LT/B2 Specifications
Manufacturer: Oxley
Part Number: 050/LT/B2
Product Type: PCB test point
Series: Snale Snaplox Series
Connector Type: Printed circuit test point
Mounting Type: Through-hole
Contact Material: Brass
Contact Plating: Palladium or gold finish depending on variant
Mounting Hole Diameter: ~1.4 mm typical
Operating Temperature Range: -55 °C to +125 °C typical
Current Rating: Up to ~7 A typical
RoHS Compliance: Yes Newark+1
Key Features
The 050/LT/B2 is a Snale Snaplox printed circuit test point designed for PCB probing and signal access. Additionally, its through-hole mounting provides robust mechanical retention. Moreover, the brass contact offers good conductivity and durability. Furthermore, the Snaplox design supports reliable engagement with test probes and connectors. Therefore, it aids measurement setup and functional testing.
Applications
PCB functional test points
In-circuit probe access
Manufacturing test fixtures
Automated test equipment
Board validation checkpoints
Maintenance and diagnostics ports
Communication interface test points
Quality assurance stations
Product Overview
The Oxley 050/LT/B2 test point is part of the Snale Snaplox interconnect series and provides a dependable access point for electrical testing. Specifically, it is designed to mount through the PCB and present a stable, easily probed contact. As a result, engineers and technicians can quickly access signals during manufacturing and field diagnostics. Moreover, the brass contact material delivers solid conductivity and resilience. Therefore, signal integrity remains consistent across repeated test cycles. In addition, the typical mounting hole diameter of around 1.4 mm enables straightforward panel preparation. Furthermore, RoHS compliance ensures compatibility with modern lead-free assembly standards. Consequently, this test point suits a range of industrial and electronics manufacturing environments. Overall, the 050/LT/B2 combines reliability, ease of use, and mechanical stability. Therefore, it provides a practical solution for PCB test access in demanding designs.
Contact Us
For pricing, lead time, and technical assistance, Cyndtek is ready to help. Moreover, our team supports OEMs, CMs, and engineers with dependable component solutions. Please contact us today to discuss availability.
Email: Sales@Cyndtek.com
For additional available stock, browse our full inventory.
