70247-1051

70247-1051 Specifications

Manufacturer: Molex
Part Number: 70247-1051
Product Type: 2.54mm Pitch C-Grid Header
Number of Positions: 10
Number of Rows: 2
Pitch – Mating Interface: 2.54 mm
Row Spacing – Mating: 2.54 mm
Mounting Type: Through Hole, Right Angle
Termination: Solder
Contact Type: Male Pin
Contact Material: Phosphor Bronze
Plating Contact  – Mating: Gold (0.38 µm)
Contact Plating – Termination: Tin (1.90 µm)
Insulation Material: Polyester (PBT), Glass Filled
Color – Resin: Black
Current Rating (Amps): 2.5A
Voltage Rating: 250V DC
Operating Temperature Range: -55°C to +120°C
Durability (mating cycles max): 50
Flammability Rating: UL94 V-0
PCB Thickness – Recommended: 1.60 mm
Packaging Type: Tray
Compliance: RoHS Compliant

Key Features

The Molex 70247-1051 is a 2.54mm pitch C-Grid header designed for reliable wire-to-board signal connections. Its dual-row, right-angle configuration with 10 positions allows for efficient use of PCB space. The fully shrouded design provides protection against misalignment during mating, enhancing connection integrity. Gold-plated phosphor bronze contacts ensure excellent conductivity and resistance to corrosion, supporting a current rating of up to 2.5A per contact. The black, glass-filled polyester housing offers durability and meets UL94 V-0 flammability standards, ensuring compliance with stringent safety requirements.

Applications

Power supplies in industrial automation equipment
Data and telecommunications hardware requiring reliable signal connections
Consumer electronics such as desktop computers and servers
Automotive infotainment systems and electronic control units
Medical devices needing compact, high-reliability connectors

Product Overview

Molex’s 70247-1051 C-Grid header provides a robust solution for applications demanding dependable signal connections within a compact form factor. Its dual-row, right-angle design with a 2.54mm pitch offers design flexibility for wire-to-board configurations. The connector’s fully shrouded housing ensures secure mating and protects against misalignment, enhancing reliability in critical applications. Gold-plated phosphor bronze contacts deliver excellent electrical performance and durability, supporting up to 50 mating cycles. With a current rating of 2.5A per contact and a voltage rating of 250V DC, this connector is suitable for a wide range of signal applications. The UL94 V-0 rated polyester housing meets stringent flammability requirements, ensuring safety and compliance in various industries.
