TSW-104-08-G-S Specifications
Manufacturer: Samtec
Part Number: TSW-104-08-G-S
Connector Type: High Temperature Socket Strip
Contact Style: Socket
Number of Positions: 8 positions
Number of Rows: 2 rows
Pitch: 2.54 mm
Row Spacing: 2.54 mm
Orientation: Straight
Termination Style: Through-hole
Mounting Type: PCB mount
Contact Material: Phosphor bronze
Contact Plating: Gold over nickel
Insulation Material: High temperature plastic
Operating Temperature Range: -55 °C to +125 °C
Key Features
The TSW-104-08-G-S provides a reliable interconnect solution for dual-row PCB applications. Additionally, the gold over nickel plated contacts improve conductivity and offer excellent corrosion resistance. Moreover, the high temperature plastic housing supports automated soldering processes. Furthermore, the socket contact design ensures consistent mating force and dependable performance across repeated cycles.
Applications
Industrial control boards
Embedded computing modules
Power management PCBs
Factory automation controllers
Test and measurement equipment
Telecommunications infrastructure
Motor drive control boards
High-reliability prototyping systems
Product Overview
The Samtec TSW-104-08-G-S socket strip delivers a dependable board-to-board connection solution for through-hole PCB mounting. Specifically, it supports dual-row configurations that maximize signal routing without increasing board size. As a result, designers can achieve compact layouts while maintaining robust electrical performance. Moreover, the gold plated phosphor bronze contacts provide enhanced conductivity and long-term corrosion protection. Therefore, this socket strip performs well in environments that require repeated mating cycles and reliable contact retention.
In addition, the high temperature plastic housing withstands elevated soldering temperatures and supports automated assembly processes. Furthermore, the straight orientation simplifies vertical board stacking and alignment. Consequently, the TSW-104-08-G-S integrates seamlessly into high-density systems where performance and reliability are critical. Because of this, engineers can rely on its mechanical durability and consistent electrical contact over time.
Overall, this connector balances mechanical strength, thermal resilience, and dependable electrical performance. Therefore, it is well suited for industrial, embedded, and control applications that demand robust interconnect solutions.
Contact Us
For pricing, lead time, and technical assistance, Cyndtek is ready to help. Moreover, our team supports OEMs, CMs, and engineers with dependable component solutions. Please contact us today to discuss availability.
